Tristate Electronic Manufacturing continues to enhance its SMT capabilities with another equipment upgrade. Tristate has purchased a Speedprint SP710avi Automatic Inline Stencil printer. Speedprint SP710avi Automatic Inline Stencil Customer Advantages Dual Dispenser option allows dispensing of Epoxy / Glue to stake high mass components to the PCB for reflow. Allows dispensing for pin-in-paste as well as other custom paste applications. Defect prevention verifies solder paste presence, and safeguards against insufficient paste volume. Improved accuracy and repeatability of stencil prints on dual sided products. SP710avi Specifications One Micron Resolution Linear Encoders 20um process performance 2.0 CPK 6 Sigma Closed loop squeegee pressure control Fully Automatic stencil positioning Optical Inspection of the paste bead 2D+ Paste inspection and Bridge Detection
We are always looking for talent in the following area. Candidates for the Surface Mount Technology (SMT) Assembly Technician position must be able to read and interpret bills of material, CAD/assembly drawings, routings, and follow strict process requirements. Knowledge of convection/air reflow soldering, hand soldering, and rework techniques of 0402 size and smaller components is necessary. The candidate must be able to use a microscope and minute soldering iron to perform very tedious operations, and learn codes for component recognition. Please submit resumes to: firstname.lastname@example.org.
Tristate Electronic Manufacturing is pleased to announce the addition of in house X-ray capabilities. Previously a subcontracted service, Tristate has purchased a Glenbrook Technologies JewelBox-70T to better service our customer base with their x-ray requirements. The JewelBox-70T delivers superior image quality with excellent resolution and sensitivity for laboratory and failure analysis applications. The system's high-resolution x-ray camera and 10-micron MicroTech™ x-ray source provides magnification from 7X to 2000X with resolution of 100 line pairs/mm. The ability to manipulate the subject with the five-axis positioner and simultaneously view it from any angle allows the operator to produce accurate images quickly.
We are pleased to announce the purchase of Universal’s AdVantis 3 Platform, AC-30S single beam Lightning SMT machine. The latest release in Universal's Advantis Platform lineup – Advantis 3 – is the most powerful solution available for the growing technological and capital demands of cost-sensitive business sectors. Advantis 3 delivers targeted functionality tailored to meet all of the production needs in the midrange market, with the high-end performance to distinguish Advantis 3 in its class. With the ever increasing challenges of today’s surface mount packaging, it is imperative that we invest in the capital equipment necessary to support not only our customers’ needs today but tomorrow’s as well. Ryan Null, President Tristate Electronic Manufacturing, Inc. Class-leading Performance 34,500 CPH and picks from trays and tape feeders Board size capability of [...]
In response to our record breaking 2014 , Tristate is kicking off the year with additional equipment and personnel to support our 2015 growth objectives. Ryan Null (Tristate President) said he was pleased to be reinvesting in both equipment upgrades and staffing. These commitments will allow us to stay ahead of the curve to better serve our ever growing customer base with on time delivery and customer responsiveness. High-performance Gold Plus 60 25+ New Dual-lane Feeders 60 msec index speed (4mm index) 8mm tape width, multi-pitch Allows up to 144 inputs/machine Feeder Bank Change Cart Reduces changeover time with offline feeder setup and full bank exchange Perform entire bank changeovers in minutes Model VPD3-1M Depaneler Separates .030”-.040” from score line without damage to components Employees 20% increase [...]
